Casing:High-quality galvanized steel with powder coating, excellent corrosion resistance; side panels secured with screws for tight sealing.
Double Water Pan:Angled diamond outer pan for smooth, residue-free drainage; aluminum trough inner pan.
Coils:Ø9.52mm internally grooved copper tubes, 36x31.18 inverted delta arrangement for large heat transfer area and small temperature difference.
Fins:Hydrophilic corrugated aluminum fins with 4.5mm, 6.0mm, and 9.0mm fin spacing to meet various temperature and humidity requirements.
Fan Cowl:Integrated large arc design for good airflow, long throw, and low noise.
Fans:High-power external rotor fans, operating temperature -20℃ to -40℃; available in Ø350, Ø400, and Ø450 sizes.
Defrost:Standard electric defrost with stainless steel heating tubes evenly distributed in coil fins and inner water pan; independent heating tube junction box. Optional accessories like expansion valves and fan ring heating belts are available upon request.
Refrigerants:Compatible with R404A, R507A, R448A, R449A, R134A, R22, etc.
Product Parameters
| Model | Refrigeration Capacity/R404A(KW) | Area m² | Tube Volume dm³ | Air Volume m³/h | Range m | Fan | Water Interface (mm) | Frost Water m³/h | Weight kg |
Tc=0℃
△T=8K | Tc=-18℃
△T=7K | Power (W) | Electric Current (A) | Water Intake | Drainage |
| 450 Fan Series |
| XW4.5/451MA | 4.5 | 3.5 | 25.3 | 3.9 | 4300 | 12 | 290 | 0.59 | G1.5 " | G2.5 " | 1.08 | 60 |
| XW5.4/451MA | 5.4 | 4.2 | 33.7 | 5.3 | 3900 | 12 | 290 | 0.59 | G1.5 " | G2.5 " | 1.29 | 65 |
| XW9.1/452MA | 9.1 | 7.1 | 50.5 | 7.9 | 8600 | 13 | 580 | 1.18 | G1.5 " | G2.5 " | 2.18 | 101 |
| XW10.8/452MA | 10.8 | 8.4 | 67.4 | 10.5 | 7800 | 13 | 580 | 1.18 | G1.5 " | G2.5 " | 2.58 | 111 |
| XW14.0/453MA | 14.0 | 10.9 | 77.6 | 11.8 | 12900 | 14 | 870 | 1.77 | G1.5 " | G2.5 " | 3.35 | 144 |
| XW16.6/453MA | 16.6 | 12.9 | 107.6 | 15.8 | 11700 | 14 | 870 | 1.77 | G1.5 " | G2.5 " | 3.97 | 160 |
| XW18.2/454MA | 18.2 | 14.2 | 101.1 | 15.8 | 17200 | 15 | 1160 | 2.36 | 2-G1.5 " | G3 " | 4.35 | 183 |
| XW21.6/454MA | 21.6 | 16.8 | 134.8 | 21.0 | 15600 | 15 | 1160 | 2.36 | 2-G1.5 " | G3 " | 5.17 | 203 |
| 550 Fan Series |
| XW9.8/551MA | 9.8 | 7.6 | 54.5 | 8.5 | 7400 | 18 | 670 | 1.27 | G1.5 " | G2.5 " | 2.34 | 98 |
| XW11.4/551MA | 11.4 | 8.9 | 68.0 | 10.6 | 7000 | 18 | 670 | 1.27 | G1.5 " | G2.5 " | 2.73 | 106 |
| XW12.5/551MA | 12.5 | 9.8 | 81.6 | 12.7 | 6600 | 18 | 670 | 1.27 | G1.5 " | G2.5 " | 2.99 | 114 |
| XW19.6/552MA | 19.6 | 15.3 | 108.8 | 17.0 | 14800 | 20 | 1340 | 2.54 | G1.5 " | G2.5 " | 4.69 | 171 |
| XW22.9/552MA | 22.9 | 17.9 | 136.0 | 21.2 | 14000 | 20 | 1340 | 2.54 | G1.5 " | G2.5 " | 5.48 | 187 |
| XW25.0/552MA | 25.0 | 19.5 | 163.3 | 25.5 | 13200 | 20 | 1340 | 2.54 | G1.5 " | G2.5 " | 5.98 | 203 |
| XW29.4/553MA | 29.4 | 22.9 | 163.3 | 25.5 | 22200 | 22 | 2010 | 3.81 | 2-G1.5 " | G3 " | 7.03 | 244 |
| XW34.3/553MA | 34.3 | 26.8 | 204.1 | 31.8 | 21000 | 22 | 2010 | 3.81 | 2-G1.5 " | G3 " | 8.21 | 269 |
| XW37.5/553MA | 37.5 | 29.3 | 244.9 | 38.2 | 19800 | 22 | 2010 | 3.81 | 2-G1.5 " | G3 " | 8.97 | 294 |
| XW39.2/554MA | 39.2 | 30.6 | 217.7 | 34.0 | 29600 | 24 | 2680 | 5.08 | 2-G1.5 " | G3 " | 9.38 | 319 |
| XW45.7/554MA | 45.7 | 35.6 | 272.1 | 42.5 | 28000 | 24 | 2680 | 5.08 | 2-G1.5 " | G3 " | 10.93 | 350 |
| XW50.0/554MA | 50.0 | 39.0 | 326.5 | 50.9 | 26400 | 24 | 2680 | 5.08 | 2-G1.5 " | G3 " | 11.96 | 382 |
| 630 Fan Series |
| XW15.9/631MA | 15.9 | 12.4 | 93.3 | 14.6 | 10100 | 28 | 937 | 1.75 | G1.5 " | G2.5 " | 3.80 | 144 |
| XW18.8/631MA | 18.8 | 14.7 | 116.6 | 18.2 | 9800 | 28 | 937 | 1.75 | G1.5 " | G2.5 " | 4.50 | 158 |
| XW21.0/631MA | 21.0 | 16.4 | 139.9 | 21.8 | 9500 | 28 | 937 | 1.75 | G1.5 " | G2.5 " | 5.02 | 172 |
| XW31.7/632MA | 31.7 | 24.7 | 186.6 | 29.1 | 20200 | 30 | 1874 | 3.5 | G1.5 " | G2.5 " | 7.58 | 255 |
| XW37.3/632MA | 37.3 | 29.1 | 233.2 | 36.4 | 19600 | 30 | 1874 | 3.5 | G1.5 " | G2.5 " | 8.92 | 283 |
| XW42.0/632MA | 42.0 | 32.8 | 279.9 | 43.7 | 19000 | 30 | 1874 | 3.5 | G1.5 " | G2.5 " | 10.05 | 310 |
| XW47.6/633MA | 47.6 | 37.1 | 279.9 | 43.7 | 30300 | 32 | 2811 | 5.25 | 2-G1.5 " | G3 " | 11.39 | 367 |
| XW56.0/633MA | 56.0 | 43.7 | 349.8 | 54.6 | 29400 | 32 | 2811 | 5.25 | 2-G1.5 " | G3 " | 13.40 | 408 |
| XW63.0/633MA | 63.0 | 49.1 | 419.8 | 65.5 | 28500 | 32 | 2811 | 5.25 | 2-G1.5 " | G3 " | 15.07 | 449 |
|
| Model | Refrigeration Capacity/R404A(KW) | Area m² | Tube Volume dm³ | Air Volume m³/h | Range m | Fan | Water Interface (mm) | Frost Water m³/h | Weight kg |
Tc=0℃
△T=8K | Tc=-18℃
△T=7K | Power (W) | Electric Current (A) | Water Intake | Drainage |
| 450 Fan Series |
| XW2.7/451LA | 3.5 | 2.7 | 19.2 | 3.9 | 4500 | 12 | 290 | 0.59 | G1.5" | G2.5" | 0.65 | 60 |
| XW3.2/451LA | 4.1 | 3.2 | 25.6 | 5.3 | 4100 | 12 | 290 | 0.59 | G1.5" | G2.5" | 0.77 | 64 |
| XW5.5/452LA | 7.1 | 5.5 | 38.4 | 7.9 | 9000 | 13 | 580 | 1.18 | G1.5" | G2.5" | 1.32 | 100 |
| XW6.5/452LA | 8.3 | 6.5 | 51.3 | 10.5 | 8200 | 13 | 580 | 1.18 | G1.5" | G2.5" | 1.56 | 108 |
| XW8.3/453LA | 10.6 | 8.3 | 59.2 | 11.8 | 13500 | 14 | 870 | 1.77 | G1.5" | G2.5" | 1.99 | 136 |
| XW9.8/453LA | 12.6 | 9.8 | 78.9 | 15.8 | 12300 | 14 | 870 | 1.77 | G1.5" | G2.5" | 2.34 | 149 |
| XW11.1/454LA | 14.2 | 11.1 | 76.9 | 15.8 | 18000 | 15 | 1160 | 2.36 | 2-G1.5" | G3" | 2.66 | 172 |
| XW13.2/454LA | 16.9 | 13.2 | 102.5 | 21.0 | 16400 | 15 | 1160 | 2.36 | 2-G1.5" | G3" | 3.16 | 189 |
| 550 Fan Series |
| XW6.6/551LA | 8.5 | 6.6 | 41.5 | 8.5 | 7600 | 18 | 670 | 1.27 | G1.5" | G2.5" | 1.58 | 96 |
| XW7.9/551LA | 10.1 | 7.9 | 51.8 | 10.6 | 7200 | 18 | 670 | 1.27 | G1.5" | G2.5" | 1.89 | 103 |
| XW8.9/551LA | 11.4 | 8.9 | 62.1 | 12.7 | 6900 | 18 | 670 | 1.27 | G1.5" | G2.5" | 2.13 | 110 |
| XW13.3/552LA | 17.1 | 13.3 | 82.8 | 17.0 | 15200 | 20 | 1340 | 2.54 | G1.5" | G2.5" | 3.18 | 160 |
| XW15.7/552LA | 20.1 | 15.7 | 103.5 | 21.2 | 14400 | 20 | 1340 | 2.54 | G1.5" | G2.5" | 3.76 | 173 |
| XW17.9/552LA | 22.9 | 17.9 | 124.2 | 25.5 | 13800 | 20 | 1340 | 2.54 | G1.5" | G2.5" | 4.28 | 186 |
| XW19.9/553LA | 25.5 | 19.9 | 124.2 | 25.5 | 22800 | 22 | 2010 | 3.81 | 2-G1.5" | G3" | 4.76 | 228 |
| XW23.6/553LA | 30.3 | 23.6 | 155.3 | 31.8 | 21600 | 22 | 2010 | 3.81 | 2-G1.5" | G3" | 5.65 | 248 |
| XW26.8/553LA | 34.4 | 26.8 | 186.3 | 38.2 | 20700 | 22 | 2010 | 3.81 | 2-G1.5" | G3" | 6.41 | 268 |
| XW26.5/554LA | 34.0 | 26.5 | 165.6 | 34.0 | 30400 | 24 | 2680 | 5.08 | 2-G1.5" | G3" | 6.34 | 295 |
| XW31.5/554LA | 40.4 | 31.5 | 207.0 | 42.5 | 28800 | 24 | 2680 | 5.08 | 2-G1.5" | G3" | 7.54 | 321 |
| XW35.8/554LA | 45.9 | 35.8 | 248.5 | 50.9 | 27600 | 24 | 2680 | 5.08 | 2-G1.5" | G3" | 8.56 | 347 |
| 630 Fan Series |
| XW10.8/631LA | 13.8 | 10.8 | 71.0 | 14.6 | 10200 | 28 | 937 | 1.75 | G1.5" | G2.5" | 2.58 | 139 |
| XW12.8/631LA | 16.4 | 12.8 | 88.7 | 18.2 | 9900 | 28 | 937 | 1.75 | G1.5" | G2.5" | 3.06 | 152 |
| XW14.5/631LA | 18.6 | 14.5 | 106.5 | 21.8 | 9600 | 28 | 937 | 1.75 | G1.5" | G2.5" | 3.47 | 163 |
| XW21.6/632LA | 27.7 | 21.6 | 142.0 | 29.1 | 20400 | 30 | 1874 | 3.5 | G1.5" | G2.5" | 5.17 | 239 |
| XW25.6/632LA | 32.8 | 25.6 | 177.5 | 36.4 | 19800 | 30 | 1874 | 3.5 | G1.5" | G2.5" | 6.12 | 262 |
| XW29.0/632LA | 37.2 | 29.0 | 212.9 | 43.7 | 19200 | 30 | 1874 | 3.5 | G1.5" | G2.5" | 6.94 | 285 |
| XW32.5/633LA | 41.7 | 32.5 | 212.9 | 43.7 | 30600 | 32 | 2811 | 5.25 | 2-G1.5" | G3" | 7.78 | 343 |
| XW38.3/633LA | 49.1 | 38.3 | 266.2 | 54.6 | 29700 | 32 | 2811 | 5.25 | 2-G1.5" | G3" | 9.16 | 378 |
| XW43.7/633LA | 56.0 | 43.7 | 319.4 | 65.5 | 28800 | 32 | 2811 | 5.25 | 2-G1.5" | G3" | 10.45 | 413 |
|
| Model | Refrigeration Capacity/R404A(KW) | Area m² | Tube Volume dm³ | Air Volume m³/h | Range m | Fan | Water Interface (mm) | Frost Water m³/h | Weight kg |
Tc=0℃
△T=8K | Tc=-18℃
△T=7K | Power (W) | Electric Current (A) | Water Intake | Drainage |
| 450 Fan Series |
| XW2.2/451JA | 2.8 | 2.2 | 13.2 | 3.9 | 4700 | 12 | 290 | 0.59 | G1.5" | G2.5" | 0.53 | 57 |
| XW2.6/451JA | 3.3 | 2.6 | 17.6 | 5.3 | 4300 | 12 | 290 | 0.59 | G1.5" | G2.5" | 0.62 | 61 |
| XW4.3/452JA | 5.5 | 4.3 | 26.4 | 7.9 | 9400 | 13 | 580 | 1.18 | G1.5" | G2.5" | 1.03 | 94 |
| XW5.2/452JA | 6.7 | 5.2 | 35.2 | 10.5 | 8600 | 13 | 580 | 1.18 | G1.5" | G2.5" | 1.24 | 101 |
| XW6.7/453JA | 8.6 | 6.7 | 40.6 | 11.8 | 14100 | 14 | 870 | 1.77 | G1.5" | G2.5" | 1.60 | 128 |
| XW8.0/453JA | 10.3 | 8.0 | 54.1 | 15.8 | 12900 | 14 | 870 | 1.77 | G1.5" | G2.5" | 1.91 | 138 |
| XW8.5/454JA | 10.9 | 8.5 | 52.7 | 15.8 | 18800 | 15 | 1160 | 2.36 | 2-G1.5" | G3" | 2.03 | 162 |
| XW10.5/454JA | 13.5 | 10.5 | 70.3 | 21.0 | 17200 | 15 | 1160 | 2.36 | 2-G1.5" | G3" | 2.51 | 175 |
| 550 Fan Series |
| XW5.7/551JA | 7.3 | 5.7 | 28.5 | 8.5 | 7800 | 18 | 670 | 1.27 | G1.5" | G2.5" | 1.36 | 90 |
| XW6.9/551JA | 8.8 | 6.9 | 35.5 | 10.6 | 7500 | 18 | 670 | 1.27 | G1.5" | G2.5" | 1.65 | 96 |
| XW7.9/551JA | 10.1 | 7.9 | 42.6 | 12.7 | 7200 | 18 | 670 | 1.27 | G1.5" | G2.5" | 1.89 | 101 |
| XW11.5/552JA | 14.7 | 11.5 | 56.8 | 17.0 | 15600 | 20 | 1340 | 2.54 | G1.5" | G2.5" | 2.75 | 148 |
| XW13.6/552JA | 17.4 | 13.6 | 71.2 | 21.2 | 15000 | 20 | 1340 | 2.54 | G1.5" | G2.5" | 3.25 | 158 |
| XW15.8/552JA | 20.3 | 15.8 | 85.2 | 25.5 | 14400 | 20 | 1340 | 2.54 | G1.5" | G2.5" | 3.78 | 169 |
| XW17.0/553JA | 21.8 | 17.0 | 85.2 | 25.5 | 23400 | 22 | 2010 | 3.81 | 2-G1.5" | G3" | 4.07 | 210 |
| XW20.5/553JA | 26.3 | 20.5 | 106.5 | 31.8 | 22500 | 22 | 2010 | 3.81 | 2-G1.5" | G3" | 4.90 | 226 |
| XW23.6/553JA | 30.3 | 23.6 | 127.8 | 38.2 | 21600 | 22 | 2010 | 3.81 | 2-G1.5" | G3" | 5.65 | 243 |
| XW22.6/554JA | 29.0 | 22.6 | 112.6 | 34.0 | 31200 | 24 | 2680 | 5.08 | 2-G1.5" | G3" | 5.41 | 273 |
| XW27.2/554JA | 34.9 | 27.2 | 142.0 | 42.5 | 30000 | 24 | 2680 | 5.08 | 2-G1.5" | G3" | 6.51 | 292 |
| XW31.8/554JA | 40.8 | 31.8 | 170.5 | 50.9 | 28800 | 24 | 2680 | 5.08 | 2-G1.5" | G3" | 7.61 | 313 |
| 630 Fan Series |
| XW9.0/631JA | 11.5 | 9.0 | 48.7 | 14.6 | 10300 | 28 | 937 | 1.75 | G1.5" | G2.5" | 2.15 | 129 |
| XW10.5/631JA | 13.5 | 10.5 | 60.8 | 18.2 | 10000 | 28 | 937 | 1.75 | G1.5" | G2.5" | 2.51 | 139 |
| XW11.7/631JA | 15.0 | 11.7 | 73.0 | 21.8 | 9700 | 28 | 937 | 1.75 | G1.5" | G2.5" | 2.80 | 148 |
| XW17.9/632JA | 22.9 | 17.9 | 97.4 | 29.1 | 20600 | 30 | 1874 | 3.50 | G1.5" | G2.5" | 4.28 | 219 |
| XW20.9/632JA | 26.8 | 20.9 | 121.7 | 36.4 | 20000 | 30 | 1874 | 3.50 | G1.5" | G2.5" | 5.00 | 238 |
| XW23.4/632JA | 30.0 | 23.4 | 146.0 | 43.7 | 19400 | 30 | 1874 | 3.50 | G1.5" | G2.5" | 5.60 | 255 |
| XW26.9/633JA | 34.5 | 26.9 | 146.0 | 43.7 | 30900 | 32 | 2811 | 5.25 | 2-G1.5" | G3" | 6.44 | 313 |
| XW31.4/633JA | 40.3 | 31.4 | 182.5 | 54.6 | 30000 | 32 | 2811 | 5.25 | 2-G1.5" | G3" | 7.51 | 340 |
| XW35.0/633JA | 44.9 | 35.0 | 219.1 | 65.5 | 29100 | 32 | 2811 | 5.25 | 2-G1.5" | G3" | 8.37 | 368 |
|
| Model | External Dimensions (mm) | Installation Size (mm) |
| L | W | H | A | B | 1 | B2 | B3 | C | Mounting Hole |
| XW*/451** | 1060 | 650 | 920 | 580 | 690 | / | / | / | 450 | 4-Φ13 |
| XW*/452** | 1710 | 650 | 920 | 580 | 1340 | / | / | / | 450 | 4-Φ13 |
| XW*/453** | 2360 | 650 | 920 | 580 | 1990 | / | / | / | 450 | 4-Φ13 |
| XW*/454** | 3010 | 650 | 920 | 580 | 2640 | / | 1320 | / | 450 | 6-Φ13 |
| XW*/551** | 1310 | 720 | 1020 | 635 | 940 | / | / | / | 550 | 4-Φ13 |
| XW*/552** | 2210 | 720 | 1020 | 635 | 1840 | 920 | / | / | 550 | 6-Φ13 |
| XW*/553** | 3110 | 720 | 1020 | 635 | 2740 | 920 | 1820 | / | 550 | 8-Φ13 |
| XW*/554** | 4010 | 720 | 1020 | 635 | 3640 | 920 | 1820 | 2720 | 550 | 10-Φ13 |
| XW*/631** | 1610 | 750 | 1200 | 660 | 1240 | / | / | / | 600 | 4-Φ13 |
| XW*/632** | 2810 | 750 | 1200 | 660 | 2440 | 1220 | / | / | 600 | 6-Φ13 |
| XW*/633** | 4010 | 750 | 1200 | 660 | 3640 | 1220 | 2420 | / | 600 | 8-Φ13 |
